| Code EAN13: | 8008379070442 |
|---|---|
| Standard packing: | 1,00 |
| Minimum packaging: | 1,00 |
| Code EAN13 min.pck.: | 8008379070442 |
| Length min.pck.: | 53,00 |
| Width min.pck.: | 48,00 |
| Height min.pck.: | 59,00 |
| Volume min.pck.: | 0,15 |
| Weight min.pck.: | 91,00 |
| Quantity min. order: | 1,00 |
| Reference Metel: | SHUTTERS MOTORS ACTUATOR LIFE 2M |
| Product status: | In Stock |
| Mounting method: | Built-in installation |
|---|---|
| Type of current: | AC/DC |
| Number of inputs: | |
| Bus system KNX: | No |
| Bus system radio frequent: | No |
| Bus system Powernet: | No |
| With bus connection: | Si |
| Max. number of venetian-blind outputs: | 1 |
| Switching current (resistive): | 10 |
| Width in number of modular spacings: | 2 |
| Other bus systems: | Other |
|---|---|
| Bus system LON: | No |
| Local operation/hand operation: | Si |
| With switch function: | Si |
| Degree of protection (IP): | IP41 |
| With LED indication: | Si |
| Bus system KNX radio: | No |
| Radio frequent bidirectional: | No |
| Bus module detachable: | No |
AVE reserves the right to modify the characteristics of the products shown at any time and without notice. The installation must be carried out by qualified personnel in compliance with the provisions governing the installation of electrical equipment in force in the country where the products are installed. For the conditions of use of the information on the product sheet see conditions of use.
